Metered C-12H0 3.3kW (12) C13 outlets Rack PDU

Key Features

Branch Circuit Protection

This rack PDU meets the UL and IEC 60950-1 requirement for branch circuit protection through use of UL489 rated magnetic-hydraulic circuit breakers or UL248 fuses.
Color Identification

Choose from six colors to designate circuits for rack PDUs in the data center. Color options include Blue, Red, Green, White, Yellow, and Black.

Family Description

The Server Technology® Metered PDU provides reliable power distribution with local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet.
Family Specifications
- Branch Monitoring: None
- Branch Overcurrent Protection:
- Branch Overcurrent Protection Type: None
- Dual Input: No
- High Retention Outlets: No
- Input Current Display: Standard
- Input Monitoring: Current (A)
- Locking Outlets: No
- Max Operating Temperature: 60 °C
- Fast Movers: No
- Mounting: 1U Horizontal
- Outlet Monitoring: None
- PDU Platform: None
- Power Pivot Input: No
- Product Height (inch): 1.75
- Product Height (mm): 45
- Product Max Depth (inch):
- Product Max Depth (mm): 0
- Product Nominal Depth (inch): 5.0
- Product Nominal Depth (mm): 127
- Product Width (inch): 17.2
- Product Width (mm): 437

★★★ C-12H0A111 (Metered) Requires PTCORD-L1, -L2, -L3, -L4, -L5, -L6, or –L7
Download Datasheet
Input Power Capacity (kW):	3.3
Input Plug Type:	IEC C20 100-240V Inlet
Input Current (A):	20
Input Current Rated (A):	16
Input Nominal Voltage (V):	208
Input Phase:	1-Phase (L-L)
Input Cord Location:	Horizontal
Outlet Form Factor:	Conventional
Total Outlets:	12
IEC C13 Count:	12
